Additional information
| Dimensions | 0.535 × 0.535 × 0.31 in |
|---|---|
| Series | 60000 |
| Application Grade | QPL |
| Mounting Type | SMD |
| Series Inductance (mH) | 7.5 |
| Series DC Current (A) | 0.17 |
| Series DCR (OHMS) | 13.75 |
| Parallel Inductance (mH) | 1.875 |
| Parallel DC Current (A) | 0.34 |
| Parallel DCR (OHMS) | 3.44 |
| DWV | 100 |
| Package Size | A-4 |
| Tolerance | ±10% |
| Termination Type | Pb |
| Termination Finish | Tin/Lead |
| Operating Temperature | -55°C to +130°C |
| Storage Temperature | -60°C to +135°C |
| Length (inches) | 0.535 |
| Width (inches) | 0.535 |
| Height (inches) | 0.31 |
