Additional information
| Dimensions | 0.7 × 0.7 × 0.41 in |
|---|---|
| Series | 60000 |
| Application Grade | QPL |
| Mounting Type | SMD |
| Series Inductance (µH) | 11 |
| Series DC Current (A) | 6 |
| Series DCR (OHMS) | 0.02 |
| Parallel Inductance (µH) | 2.75 |
| Parallel DC Current (A) | 12 |
| Parallel DCR (OHMS) | 0.005 |
| DWV | 100 |
| Package Size | A-5 |
| Tolerance | ±12% |
| Termination Type | Pb |
| Termination Finish | Tin/Lead |
| Operating Temperature | -55°C to +130°C |
| Storage Temperature | -60°C to +135°C |
| Length (inches) | 0.7 |
| Width (inches) | 0.7 |
| Height (inches) | 0.41 |
