Additional information
| Dimensions | 0.41 × 0.41 × 0.23 in |
|---|---|
| Series | S60000 |
| Application Grade | Space (MIL-STD-981) |
| Mounting Type | SMD |
| Series Inductance (mH) | 3 |
| Series DC Current (A) | 0.12 |
| Series DCR (OHMS) | 18.3 |
| Parallel Inductance (mH) | 0.75 |
| Parallel DC Current (A) | 0.24 |
| Parallel DCR (OHMS) | 4.58 |
| DWV | 100 |
| Package Size | A-2 |
| Tolerance | ±10% |
| Termination Type | Pb |
| Termination Finish | Tin/Lead |
| Operating Temperature | -55°C to +130°C |
| Storage Temperature | -60°C to +135°C |
