Additional information
| Dimensions | 0.535 × 0.535 × 0.31 in |
|---|---|
| Series | S60000 |
| Application Grade | Space (MIL-STD-981) |
| Mounting Type | SMD |
| Series Inductance (mH) | 10 |
| Series DC Current (A) | 0.14 |
| Series DCR (OHMS) | 18.25 |
| Parallel Inductance (mH) | 2.5 |
| Parallel DC Current (A) | 0.28 |
| Parallel DCR (OHMS) | 4.57 |
| DWV | 100 |
| Package Size | A-4 |
| Tolerance | ±10% |
| Termination Type | Pb |
| Termination Finish | Tin/Lead |
| Operating Temperature | -55°C to +130°C |
| Storage Temperature | -60°C to +135°C |
