Additional information
| Dimensions | 0.7 × 0.7 × 0.41 in |
|---|---|
| Series | S60000 |
| Application Grade | Space (MIL-STD-981) |
| Mounting Type | SMD |
| Series Inductance (µH) | 38 |
| Series DC Current (A) | 2.5 |
| Series DCR (OHMS) | 0.076 |
| Parallel Inductance (µH) | 9.5 |
| Parallel DC Current (A) | 5 |
| Parallel DCR (OHMS) | 0.019 |
| DWV | 100 |
| Package Size | A-5 |
| Tolerance | ±12% |
| Termination Type | Pb |
| Termination Finish | Tin/Lead |
| Operating Temperature | -55°C to +130°C |
| Storage Temperature | -60°C to +135°C |
