Additional information
| Weight | 4 g |
|---|---|
| Dimensions | 0.49 × 0.55 × 0.33 in |
| Series | HILO |
| Mounting Type | SMD |
| Application Grade | COTS+ |
| Inductance (µH) | 0.22 |
| DCR Max (OHMS) | 0.00045 |
| Rated Current (A) | 40 |
| Sat Current (A) | 60 |
| DWV | 100 |
| Termination Type | RoHS |
| Termination Finish | Pure-Tin |
| Operating Temperature | -55°C to +125°C |
| Storage Temperature | -60°C to +130°C |
