Additional information
| Dimensions | 0.105 × 0.11 × 0.07 in |
|---|---|
| Series | C30000 |
| Mounting Type | SMD |
| Application Grade | COTS+ |
| Inductance (µH) | 0.01 |
| DCR Max (OHMS) | 0.025 |
| DC Current Max (A) | 0.75 |
| Q min | 50 |
| Test Freq (MHz) | 150 |
| SRF min (GHz) | 2 |
| Tolerance | ±10% |
| Termination Type | Pb |
| Termination Finish | Tin/Lead |
| Package Options | With Tabs |
| Operating Temperature | -55°C to +125°C |
| Storage Temperature | -55°C to +125°C |
