Additional information
| Dimensions | 0.105 × 0.11 × 0.085 in |
|---|---|
| Series | S26000 |
| Mounting Type | SMD |
| Application Grade | Space (MIL-STD-981) |
| Inductance (µH) | 0.039 |
| DCR Max (OHMS) | 0.07 |
| DC Current Max (A) | 0.6 |
| Q min | 47 |
| Test Freq (MHz) | 100 |
| SRF min (GHz) | 1.2 |
| Tolerance | ±5% |
| Termination Type | RoHS |
| Termination Finish | Gold |
| Package Options | With Tabs |
| Operating Temperature | -55°C to +125°C |
| Storage Temperature | -55°C to +125°C |
