High Voltage Capabilities in Magnetic Components

Design and Application Considerations

Optimizing High-Voltage Inductors and Transformers for Reliable Performance

At Vanguard Electronics, we specialize in designing and manufacturing high-reliability magnetic components, including inductors and transformers, that can handle high-voltage applications. This application note provides a comprehensive guide on the design considerations, testing, and application of high-voltage magnetic components.

View PDF

Understanding High-Voltage Requirements

High-voltage applications, such as those in power supplies, medical devices, and aerospace systems, require magnetic components that can withstand and operate reliably under high-voltage conditions. Here are some key aspects to consider:

  • Voltage Ratings: Ensuring that the magnetic component can handle the specified voltage without breakdown or degradation.
  • Insulation: Proper insulation is critical to prevent electrical breakdowns and ensure safe operation.
  • Dielectric Strength: The component must have sufficient dielectric strength to withstand the high voltage without failing.

Core Material Selection for High-Voltage Applications

The choice of core material is crucial for high-voltage applications:

  • Ferrite Cores: While ferrite cores are commonly used, they may not be ideal for very high-voltage applications due to their limited dielectric strength.
  • Powdered Iron Cores: These cores offer better high-frequency performance and can be used in high-voltage applications, but they may require additional insulation.
  • Air Cores: Air cores can be used in high-voltage applications where the core material is not necessary, but they require careful design to ensure adequate insulation and spacing.

Design Considerations for High-Voltage Inductors

When designing high-voltage inductors, several factors must be considered:

  • Insulation and Clearances
    • Winding Insulation: Ensuring that the windings are properly insulated to prevent electrical breakdowns. This can be achieved using high-voltage insulation materials such as Kapton, Mylar, or Teflon.
    • Clearances: Maintaining sufficient clearances between the windings and the core, as well as between different windings, to prevent arcing and breakdown.
  • Winding Techniques
    • Multi-Layer Windings: Using multi-layer windings can help distribute the voltage more evenly and reduce the risk of breakdown.
    • Interleaved Windings: Interleaving the windings can help reduce leakage inductance and improve the overall performance of the inductor.
  • Core Geometry
    • Core Size and Shape: The core size and shape must be optimized to handle the high voltage without compromising the inductance value.
    • Air Gaps: Introducing air gaps in the core can help increase the breakdown voltage but may affect the inductance value.

Design Considerations for High-Voltage Transformers

Transformers in high-voltage applications require special attention:

  • Turns Ratio
    • Optimized Turns Ratio: The turns ratio must be carefully selected to match the input and output voltages while minimizing losses.
    • Voltage Transformation: Ensuring that the transformer can handle the voltage transformation without breakdown or degradation.
  • Insulation and Clearances
    • Primary and Secondary Insulation: Ensuring that both the primary and secondary windings are properly insulated to prevent electrical breakdowns.
    • Clearances: Maintaining sufficient clearances between the primary and secondary windings, as well as between the windings and the core.
  • Winding Techniques
    • Sectional Windings: Using sectional windings can help distribute the voltage more evenly and reduce the risk of breakdown.
    • Shielded Windings: Shielding the windings can help reduce electromagnetic interference (EMI) and improve the overall performance of the transformer.

Testing High-Voltage Magnetic Components

Thorough testing is essential to ensure that high-voltage magnetic components meet the required specifications:

  • Electrical Testing: Conduct comprehensive electrical tests including:
    • Dielectric Withstand Voltage (DWV) Testing: Verifying that the component can withstand the specified high voltage without breakdown.
    • Partial Discharge Testing: Detecting any partial discharges that could indicate potential breakdown points.
    • Leakage Current Testing: Measuring the leakage current to ensure it is within acceptable limits.
  • Environmental Testing: Perform environmental tests such as:
    • Thermal Testing: Testing the component’s performance under various temperature conditions to ensure reliability.
    • Vibration Testing: Testing the component’s mechanical durability under vibration to ensure it can withstand physical stresses.
    • Humidity Testing: Testing the component’s performance under various humidity conditions to ensure reliability in different environments.

Application Examples

High-voltage magnetic components are used in a variety of applications, including:

Power Supplies

  • Switch-Mode Power Supplies: High-voltage inductors and transformers are critical in switch-mode power supplies to ensure efficient and reliable operation.
  • High-Voltage DC-DC Converters: These converters require magnetic components that can handle high voltages and high currents.

Medical Devices

  • Defibrillators: High-voltage transformers are used in defibrillators to generate the high-voltage pulses necessary for cardiac defibrillation.
  • X-Ray Machines: High-voltage transformers are used in X-ray machines to generate the high voltages required for X-ray production.

Aerospace Systems

  • Power Distribution Units: High-voltage magnetic components are used in power distribution units to ensure reliable and efficient power distribution in aerospace systems.
  • Radar Systems: High-voltage transformers are used in radar systems to generate the high voltages required for radar operation.

Conclusion

Designing and testing high-voltage magnetic components require careful consideration of core material selection, insulation, winding techniques, and environmental testing. By following these guidelines, you can ensure that your high-voltage inductors and transformers operate reliably and efficiently in various applications.
